Three Tanks Solvent Industrial Ultrasonic Cleaner Adjustable Timer With SUS304 Tank

Product Details

Place of Origin: China

Brand Name: FUYANG

Certification: ce, RoHS

Model Number: F-3018

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiation

Packaging Details: 1unit/carton box

Delivery Time: 5-7working days

Payment Terms: T/T

Supply Ability: 100PCS /DAY

Get Best Price
Contact Now
Specifications
Highlight:

Adjustable Timer Industrial Ultrasonic Cleaner

,

Three Tanks Industrial Ultrasonic Cleaner

,

SUS304 Tank Industrial Ultrasonic Cleaner

Machine Type:
Industrial Ultrasonic Cleaner
Core Components:
Motor
Cleaning Process:
Cold Water Cleaning
Tank Size:
2500*1300*1000mm
Cleaning Type:
Immersion / Soak
Warranty:
1 Year
Machine Type:
Industrial Ultrasonic Cleaner
Core Components:
Motor
Cleaning Process:
Cold Water Cleaning
Tank Size:
2500*1300*1000mm
Cleaning Type:
Immersion / Soak
Warranty:
1 Year
Description
Three Tanks Solvent Industrial Ultrasonic Cleaner Adjustable Timer With SUS304 Tank

SUS304 Three Tanks Solvent Industrial Ultrasonic Cleaner Adjustable Timer

Description of Ultrasonic Cleaner

Ultrasonic cleaning is a modern, safe, efficient, most economy and fastest way for effectively removing of contaminants and tenacious deposits from objects with complex geometry. The ultrasonic cleaning benefits consist of a deep cleaning of the objects and the elimination of the risk of injury or infection with manual cleaning.

The ultrasonic cleaner is a microprocessor-controlled device that uses ultrasonic or high frequency sound waves to clean jewelry and other delicate items. Ultrasonic cleaning is based on the cavitation effect caused by high frequency ultrasonic wave vibration signals in fluid. Microscopic bubbles that expand and rapidly collapse cause cavitation, which creates an effective cleaning action on the surface of object being cleaned. Additionally, the bubbles are small enough to penetrate even microscopic crevices, cleaning them thoroughly and consistently.



Model F-3018
1st Tank Volume 61L Ultrasonic Cleaning tank with filtration cycle system
2nd Tank Volume 61L Ultrasonic Rinsng tank
3rd Tank Volume 61L Drying tank
1st tank size 500X350X350mm
2nd tank size 500X350X350mm
3rd Tank size 500X350X350mm
Ultrasonic Power 700W*2
Heating Power of Ultrasonic tank 1500W*2
Heating Power of Drying tank 1500W
Frenquency 40KHz
Drying System 1 set
Unit size 2460*1310*1050mm
Packing size 2520*1370*1170mm
Timer 0~99 minutes adjustable
Heater Room temperature~99℃ adjustable
Material SUS 304
Power Supply AC 380V 3 phase
Lead time 18 working days
Warranty 1 year warranty period, technique support all time
Certificates CE, RoHS
Advantage Filter the dirty water; keep the water clear in tank; lower the frequency of changing water




Q1.How do I get the best ultrasonic cleaning?

There are many considerations important to ultrasonic cleaning. Optimizing these variables will produce the best cleaning. The most important decisions to be made are choosing the proper cleaning solution, cleaning at the right temperature for the correct amount of time, and choosing the right size and type of ultrasonic cleaner.



Q2.Can ultrasonic cleaning damage my parts?

With certain cautions, ultrasonic cleaning is considered safe for most parts. While the effects of thousands of implosions per second is very powerful, the cleaning process is safe since the energy is localized at the microscopic level. The most important cautionary consideration is the choice of cleaning solution. Potentially adverse effects of the detergent on the material being cleaned will be enhanced by the ultrasonic.



Q3.Why is a special solution required for cleaning?

Soils adhere to the parts... if they didn't, the soil would just fall off the parts! The purpose of the solution is to break the bond between parts and their soils. Water alone has no cleaning properties. The primary purpose of the ultrasonic activity (cavitation) is to assist the solution in doing its job. An ultrasonic cleaning solution contains various ingredients designed to optimize the ultrasonic cleaning process. For example, increased cavitation levels result from reduced fluid surface tension. An ultrasonic solution will contain a good wetting agent or surfactant.



Q4.What cleaning solution should I use?

Modern ultrasonic cleaning solutions are compounded from a variety of detergents, wetting agents and other reactive components. A large variety of excellent formulations are available, designed for specific applications. Proper selection is crucial for acceptable cleaning activity and to preclude undesirable reactivity with the part being cleaned.



Q5.What cleaning solution shouldn't I use?

Flammables or solutions with low flash points should never be used. The energy released by cavitation is converted to heat and kinetic energy, generating high temperature gradients in the solution, and can create hazardous conditions with flammable liquids. Acids, bleach and bleach by-products should generally be avoided, but may be used with indirect cleaning in a proper indirect cleaning container, such as a glass beaker, and appropriate care. Acid and bleach will damage stainless steel tanks, and/or create hazardous conditions.
